This Tablet is used for selecting the required output from the LASER-OPO Assembly. It shows a plot of the current output wavelengths vs Intensity. It has buttons for pumping the OPO, and for controlling the various LASER outputs. To get a wavelength other than the first and second harmonic of oscillating frequency, click on the plot and enter the required wavelength in pop up window.
